• Monoprice Maker Select Plus Cura

In this video I go over my settings in Cura for my Monoprice Maker Select V2. If I missed something or you need more clarification let me know in the comment. These settings are to help people this model use the latest version of Cura. Firstly, you're going to want to make a custom printer profile in Cura. All you really need to make sure is that the bed dimensions are correct, along with the filament and nozzle size, and have heated bed checked. You'll need to add your own start/stop GCODE. Monoprice Maker Select is compatible with many 3D printing software, like Cura, Repetier, or Simplify 3D. Monoprice recommends you use Cura with Monoprice Maker Select. Cura is a free 3D printing software that offers a lot. It has a Quick Print mode, which is easy to use mode which you could use until you get used to 3D printing.

Monoprice Maker Select Plus Cura

• Connecting to Cura (version 15.04.6)
  • PC
    • Make sure you have Cura version 15.04.6 downloaded for PC.
    • Use the provided USB cable to connect the printer to your computer if you will be printing via USB (make sure you are not connecting into a USB 3.0 port).
    • Find Cura on your computer and open it.
    • You will be prompted with a setup screen for your first time running the program.
    • There will be a selection of printers to choose from, make sure to select the Other option at the bottom of the list.
    • This will open another window with other printer options, you would then select the Custom option at the bottom of the list and will be taken to the 'Custom Machine' tab.
    • You may choose a name for the machine, and the bed size will be Width X 200mm x Depth Y 200mm x Height Z 180mm nozzle size is 0.4mm and heated bed will be checked. Leave 'Bed Center is 0,0,0 (RoStock)' unchecked.
    • Once completed, press Finish and you will be taken to the home page of the Cura Software with an image of the empty bed along with some settings.
• • Mac
    • Make sure you have Cura version 15.04.6 Downloaded for Mac.
    • Use the provided USB cable to connect the printer to your computer if you will be printing via USB.
    • Find Cura in your applications once installed and open it.
    • You will be prompted with a setup screen for your first time running the program.
    • There will be a list of printers to select from, and you will select Other at the bottom of the list.
    • This will open another window with other printer options to choose from, and without clicking any option, you will press Next taking you to the 'Custom Machine' tab.
    • You may choose a name for the machine, and the bed size will be Width X 200mm x Depth Y 200mm x Height Z 180mm nozzle size is 0.4mm and heated bed will be checked. Leave 'Bed Center is 0,0,0 (RoStock)' unchecked.
    • Once completed, press Finish and you will be taken to the home page of the Cura Software with an image of the empty bed along with some settings.
